SG400
SG400 High-end Snow Groomer with hydrostatic transmission electronic controll------Produced by specialty machinery manufacturer HBXG with doing their utmost.
Technical Features
Snow groomer is the most high-end type in snowway construction machineries, a high-tech product integrating the best power system, electro-hydraulic control, hydraulic transmission, low-temperature materials, light-design idea and ergonomic engineering at present. Based on the strong research and development ability, HBXG producted and presented the SG400 high-end snow groomer with hydrostatic electric control through their full efforts for two years, which broke through the monopoly status owned by foreign manufacturers. All the systemic solutions of the SG400 snow groomer were designed and developed by HBXG themselves independently, and based on domestic manufacturing and supplemented by global procurement, dedicated to forge a top-class ice& snow equipment with the most comfortable operation and good experiences for customers.
Performance Parameters
Vehicle size | |
Total length of vehicle | 8.3 m |
Total height of vehicle | 2.9 m |
Track width of parking belt | 4.3m |
Maximum width of front shovel | 5.4 m |
Maximum width of snow plough | 6 .3 m |
vehicle weight | |
Weight of main body | 6,926 kg |
Track weight | 850x2 kgs |
Front shovel weight | 500 kgs |
Snow plough weight | 894 kgs |
Total weight of vehicle | 9300 kgs |
Vehicle performance | |
Radius of turning | Pivot Steering |
Max. grade ability | 45°,100% |
Max. travel speed | 18.5km/h |
Rear platform load | 800kgs |
Engine | |
Brand | Cummins |
Model | QSL8.9, inline six cylinders, high pressure common rail, electric injection, turbocharged engine. |
Displacement | 8900cc |
Power | 360 HP |
Max. torque | 1500 N.M@ 1500r/m |
Fuel consumption | 19l /hour |
Fuel tank capacity | 260l |
Hydraulic transmission system | |
Travel hydraulic system | Danfoss 100cc hydraulic pump and motor |
Snow plough hydraulic system | Danfoss 75cc hydraulic pump |
The reducer | Bonfiglioli reducer |
Cab | |
Chief operator”s seat | located in the middle of theCab, with air shock absorption, multiple Airbags and electric heating. |
Co-operator's seat | two seats, located at left and right side of the chief operator |
Display screen | 7-inch colorful display screen |
Travel control | with classic lever travel control |
Attachments control | ergonomic multi-in-one control handle |
